Bi-folding Window-Architectural Doors Windows-Alufront Windows & Doors Pty Ltd

Key Features

* Panel measures up to 700mm wide subject to project requirements and site conditions.

* Powered by hardware for high performance trouble free operation.

* Exceptional quality which operates a multi-point locking function

* Integrated Internally fitted, retractable fly screen option available

* Full perimeter, continuous weather seals provide cost-effective weatherproofing and acoustic performance

Frame Dimensions
Option 1	100 x 50 mm
Maximum Product Performance
SLS (Pa)	1600
ULS (Pa)	2000
WATER (Pa)	450
Glazing Details
Single Glazed	6 - 13.5mm
Double Glazed	18 - 30 mm
Acoustic Performance: Rw (C;Ctr)
6.38mm Laminate	29 dB
10.38mm/12/6.38mm IGU	39 dB
Maximum Recommended Sizes
Height	3000mm
Width	1000mm
Weight	80kg
Thermal Performance
Uw range SG	4.4 - 6.2
SHGC range SG	0.26 - 0.59
Uw range DG	3.2 - 4.0
SHGC range DG	0.15 - 0.51
Uw range IGU	2.8 - 3.0
SHGC range IGU	0.17 - 0.30
